Closed Belts HTD Type

Representative model: E-LTBJA-H5M150-400 Pulley Timing

P.529
Shipping
30.99 SGD 8 days Idlers
from

Volume Discount P.551
Quantity 1~9 10~
Discount Unit Price 20%
E Shipping days may differ by Quantity. Timing Belts
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material P.577
1Main Body 2Core Wire 3Canvas
Urethane Steel wire Nylon Canvas
(White) (Green) Belts Closed End
E-LTBJA (Standard) E-LTBRA (Both Sides Cloth Lined)
Pitch 1 Pitch 1 P.605

i i
2 H H Belts Open End
h 2 h
3
P.611
Belt Type Nominal Width Pitch (mm) H h i Unit weight g/m
(Width 10mm)
060 (6mm) Open End Belts Clamp Plates for
H3M 090 (9mm) 3 2.4 1.21 1.19 27
120 (12mm)
150 (15mm)
090 (9mm) P.615
H5M 150 (15mm) 5 3.8 2.08 1.72 38 5
250 (25mm)
200 (20mm)
H8M 250 (25mm) 8 6 3.38 2.62 61
300 (30mm)
400 (40mm)
EUrethane belts may change color over time, but strength, etc. will not be affected. EOperating temperature -20°C to 60°C (reference value). Idlers / Timing Belts Timing Pulleys /
ERefer to Selection of Transmission Timing Belts on DP.1596. EThis product is not suitable for non-backlash timing pulleys.
EWeight is a theoretical value for reference only, which may be different from that of the actual product.
EBecause of the welding process, there will be traces on the surface of the connection, and the allowable tension at the connection is weak, so please pay attention when selecting the type.
4Number of Teeth
1Type 2Belt Type 3Nominal Width (1 tooth increments) Allowable tension (N)
060 (6mm) 70
090 (9mm) 80
H3M 230~10000
120 (12mm) 90
E-LTBJA 150 (15mm) 110
(Standard) H5M 090 (9mm) 140~10000 165
E-LTBRA 150 (15mm) 230
250 (25mm)
400
(Both Sides Cloth Lined) 200 (20mm) 360
250 (25mm) 450
H8M 88~6250
300 (30mm) 530
400 (40mm) 650
Ekgf=N×0.101972 ETotal length is (number of teeth × pitch). EThe allowable tension is only the permissible value associated with the tensile load.
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering
Example Part Number 1Type - 2Belt Type · 3Nominal Width - 4Number of Teeth
E-LTBJA - H5M150 - 400
