Closed Belts S Type

Timing Pulley Representative model: C-LTBJA-S5M100-200

Save Up to
P.529
vs Standard Type 75% Shipping
from
Idlers 19.00 SGD 8 days

Volume Discount
P.551 Quantity 1~9 10~
Timing Belts E Shipping days may differ by Quantity. 20%
Unit Price
Discount
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material
P.577 1Main Body 2Core Wire 3Canvas
Closed End Belts Urethane Steel wire Nylon Canvas
(Green)
(White)
Pitch
P.605 C-LTBJA (Standard) Pitch 1 C-LTBRA (Both Sides Cloth Lined) 1
2 Lr 2 3 Lr
Open End Belts Ra i H i H
h
3 Ra h
P.611 Unit weight g/m
Clamp Plates for Open End Belts Belt Type Nominal Width Pitch (mm) Ra Lr H h i (Width: 10mm)
Standard Type
060 (6mm)
150 (15mm)
P.615 S3M 100 (10mm) 3 1.95 1.95 2.2 1.14 0.8 25
100(10mm)
5 S5M 150(15mm) 5 3.25 3.25 3.41 1.91 1.5 39
250(25mm)
150(15mm)
Timing Pulleys / Idlers / Timing Belts EUrethane belts may change color over time, but strength, etc. will not be affected. EOperating temperature -20°C to 60°C (reference value). 51
250(25mm)
8
5.2
5.3
3.05
2.25
5.2
S8M
300(30mm)
400(40mm)
ERefer to Selection of Transmission Timing Belts on DP.1596.
EThis product is not suitable for non-backlash timing pulleys.
EWeight is a theoretical value for reference only, which may be different from that of the actual product.

EBecause of the welding process, there will be traces on the surface of the connection, and the allowable tension at the connection is weak, so please pay attention when selecting the type.
4Number of Teeth
1Type 2Belt Type 3Nominal Width (1 tooth increments) Allowable tension (N)
060 (6mm) 70
S3M 100 (10mm) 150~10000 80
150 (15mm) 110
C-LTBJA 100 (10mm) 165
(Standard) S5M 150 (15mm) 100~10000 230
C-LTBRA 250 (25mm) 400
(Both Sides Cloth Lined) 150 (15mm) 240
S8M 250 (25mm) 88~6250 450
300 (30mm) 530
400 (40mm) 650
Ekgf=N×0.101972 ETotal length is (number of teeth × pitch). EThe allowable tension is only the permissible value associated with the tensile load.
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering
Example Part Number 1Type - 2Belt Type · 3Nominal Width - 4Number of Teeth
C-LTBJA - S5M100 - 200
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By
Type C-LTBJA Keyword closed belt MISUMI
Economy series
