Page 609 - MISUMI SINGAPORE Economy Series

Part Number Belt Circumference Pulley Timing
1Type 2Belt Number 3Nominal Width Number of Teeth Length (mm)
650T10 65 650
660T10 66 660 P.529
680T10 68 680
690T10 69 690
700T10 70 700 Idlers
720T10 72 720
750T10 75 750 P.551
780T10 78 780
810T10 81 810
840T10 84 840 Timing Belts
850T10 85 850
880T10 88 880
910T10 91 910 P.577
920T10 92 920
960T10 96 960
970T10 97 970 Belts Closed End
980T10 98 980
990T10 99 990 P.605
1010T10 101 1010
1050T10 150 105 1050
1080T10 (15mm) 108 1080 Belts Open End
1110T10 200 111 1110
1120T10 (20mm) 112 1120
1140T10 250 114 1140 P.611
C-TTBN 1150T10 (25mm) 115 1150
300
1170T10 (30mm) 117 1170
1200T10 400 120 1200 Open End Belts Clamp Plates for
1210T10 (40mm) 121 1210
1240T10 500 124 1240 P.615
1250T10 (50mm) 125 1250
1260T10 126 1260 5
1280T10 128 1280
1300T10 130 1300
1310T10 131 1310
1320T10 132 1320 Idlers / Timing Belts Timing Pulleys /
1350T10 135 1350
1390T10 139 1390
1400T10 140 1400
1420T10 142 1420
1500T10 150 1500
1600T10 160 1600
1610T10 161 1610
1750T10 175 1750
1800T10 180 1800
1880T10 188 1880
1960T10 196 1960
2020T10 202 2020
3300T10 330 3300
3500T10 350 3500
EPlease refer to the official website for more specifications
EModels C-TTBN1170T10-200, C-TTBN3300T10-200, C-TTBN3300T10-250, C-TTBN3300T10-300, C-TTBN3300T10-400, and C-TTBN3300T10-500 are currently not available for sale.
Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering
Example Part Number (1Type · 2Belt Number) - 3Nominal Width
C-TTBN1800T10 - 400
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By
Type C-TTBN Keyword timing belt t10 MISUMI
Economy series
