Part Number Number Belt Circumference Part Number Number Belt Circumference Pulley Timing
1Type 2Belt Number 3Nominal Width of Teeth Length (mm) 1Type 2Belt Number 3Nominal Width of Teeth Length (mm)
355H 71 901.7 740H 148 1879.6 P.529
360H 72 914.4 750H 150 1905.0
365H 73 927.1 760H 152 1930.4
370H 74 939.8 770H 154 1955.8
375H 75 952.5 780H 156 1981.2 Idlers
380H 76 965.2 790H 158 2006.6
385H 77 977.9 800H 160 2032.0
390H 78 990.6 810H 162 2057.4 P.551
395H 79 1003.3 820H 164 2082.8
400H 80 1016.0 830H 166 2108.2
405H 81 1028.7 840H 168 2133.6 Timing Belts
410H 82 1041.4 850H 170 2159.0
415H 83 1054.1 860H 172 2184.4
420H 84 1066.8 870H 174 2209.8 P.577
425H 85 1079.5 880H 176 2235.2
430H 86 1092.2 900H 180 2286.0
435H 87 1104.9 910H 182 2311.4
440H 88 1117.6 920H 184 2336.8 Belts Closed End
445H 89 1130.3 930H 186 2362.2
450H 90 1143.0 940H 188 2387.6
460H 92 1168.4 950H 190 2413.0 P.605
465H 93 1181.1 960H 192 2438.4
470H 94 1193.8 980H 196 2489.2
475H 95 1206.5 985H 197 2501.9 Belts Open End
480H 96 1219.2 1000H 200 2540.0
485H 97 1231.9 1020H 204 2590.8
490H 075 98 1244.6 1050H 075 210 2667.0 P.611
495H (19.1mm) 99 1257.3 1080H (19.1mm) 216 2743.2
500H 100 1270.0 1100H 100 220 2794.0
510H 100 102 1295.4 1120H (25.4mm) 224 2844.8
C-TBN 515H (25.4mm) 103 1308.1 C-TBN 1130H 150 226 2870.2 Open End Belts Clamp Plates for
1135H
520H
104
1320.8
227
2882.9
150
525H (38.1mm) 105 1333.5 1140H (38.1mm) 228 2895.6
530H 200 106 1346.2 1150H 200 230 2921.0 P.615
540H (50.8mm) 108 1371.6 1160H (50.8mm) 232 2946.4 5
545H 109 1384.3 1180H 236 2997.2
550H 110 1397.0 1200H 240 3048.0
560H 112 1422.4 1240H 248 3149.6
565H 113 1435.1 1250H 250 3175.0
570H 114 1447.8 1260H 252 3200.4
580H 116 1473.2 1270H 254 3225.8 Idlers / Timing Belts Timing Pulleys /
585H 117 1485.9 1300H 260 3302.0
590H 118 1498.6 1325H 265 3365.5
600H 120 1524.0 1350H 270 3429.0
605H 121 1536.7 1400H 280 3556.0
610H 122 1549.4 1440H 288 3657.6
615H 123 1562.1 1450H 290 3683.0
620H 124 1574.8 1500H 300 3810.0
625H 125 1587.5 1510H 302 3835.4
630H 126 1600.2 1550H 310 3937.0
640H 128 1625.6 1560H 312 3962.4
645H 129 1638.3 1600H 320 4064.0
650H 130 1651.0 1650H 330 4191.0
660H 132 1676.4 1680H 336 4267.2
670H 134 1701.8 1700H 340 4318.0
680H 136 1727.2 1750H 350 4445.0
690H 138 1752.6 1800H 360 4572.0
700H 140 1778.0 1850H 370 4699.0
710H 142 1803.4 1900H 380 4826.0
720H 144 1828.8 2100H 420 5334.0
725H 145 1841.5 2160H 432 5486.4
730H 146 1854.2 EPlease refer to the official website for more specifications
EBelt circumference length is a reference value.
EModels C-TBN2160H075, C-TBN2160H100 and C-TBN2160H150 are currently not available for sale.
Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering
Example Part Number (1Type · 2Belt Number · 3Nominal Belt Width)
C-TBN315H150
