Page 618 - MISUMI SINGAPORE Economy Series

Open End Belts XL / L / H Type

Timing Pulley Representative model: E-HTBO-L050-200

Save Up to
P.529
vs Standard Type 51% Shipping
from
Idlers 16.00 SGD 7 days

Volume Discount
P.551 Quantity 1~9 10~
Timing Belts E Shipping days may differ by Quantity. 20%
Discount
Unit Price
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material
P.577 1Main Body 2Core Wire Pitch 1
Closed End Belts Urethane (White) Steel wire 2 i h H

P.605 θ θ Lr
Open End Belts Belt Type Nominal Width Pitch (mm) 2θ(°) H h i Lr Unit weight g/m

(Width 10mm)
P.611 XL 025 (6.4mm) 5.08 50° 2.3 1.27 1.03 2.57 24
037 (9.5mm)
050 (12.7mm)
Clamp Plates for Open End Belts L 050 (12.7mm) 9.525 40° 3.6 1.69 1.91 4.65 37
075 (19.1mm)
100 (25.4mm)
075 (19.1mm)
P.615 150 (38.1mm)
5 H 100 (25.4mm) 12.7 40° 4.3 2.29 2.01 6.12 45
150 (38.1mm)
200 (50.8mm)
Timing Pulleys / Idlers / Timing Belts EUrethane belts may change color over time, but strength, etc. will not be affected. EOperating temperature -20°C to 60°C.
ERefer to Selection of Transmission Timing Belts on DP.1596.
EThis is the calculated value. MISUMI takes the number of teeth as the basis for shipment. EThis product is not suitable for non-backlash timing pulleys.
EWeight is a theoretical value for reference only, which may be different from that of the actual product.
4Number of Teeth
2Belt Type
3Nominal Width
1Type
025 (6.4mm) (1 tooth increments) Allowable tension (N)
127
XL 037 (9.5mm) 40~10000 145
050 (12.7mm) 159
050 (12.7mm) 270
075 (19.1mm) 404
E-HTBO L 100 (25.4mm) 40~10000 539
150 (38.1mm) 809
075 (19.1mm) 404
H 100 (25.4mm) 45~10000 539
150 (38.1mm) 809
200 (50.8mm) 1078
ETotal length is (number of teeth × pitch). Ekgf=N×0.101972
EThe allowable tension is only the permissible value associated with the tensile load.
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering
Example Part Number 1Type - 2Belt Type · 3Nominal Width - 4Number of Teeth
E-HTBO - L050 - 200
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By
Type E-HTBO Keyword open belt MISUMI
Economy series
