Open End Belts T Type

Representative model: C-TTBO-T5100-200 Pulley Timing
Save Up to
vs Standard Type 64% Shipping P.529
8.00 SGD 7 days Idlers
from

Volume Discount P.551
Quantity 1~9 10~
Discount Unit Price 20%
E Shipping days may differ by Quantity. Timing Belts
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material Pitch 1 P.577
1Main Body 2Core Wire
Urethane (White) Steel wire
i
H Belts Closed End
h
2
θ θ L
P.605

Belt Type Nominal Width Pitch (mm) 2θ(°) H h i L Unit weight g/m Belts Open End
(Width 10mm)
100 (10mm) P.611
T5 150 (15mm) 5 2.2 1.2 1 1.8 25
200 (20mm)
250 (25mm) Open End Belts Clamp Plates for
150 (15mm) 40
200 (20mm) P.615
T10 250 (25mm) 10 4.5 2.5 2 3.5 46
300 (30mm) 5
400 (40mm)
500 (50mm)
EUrethane belts may change color over time, but strength, etc. will not be affected. EOperating temperature -20°C to 60°C.
ERefer to Selection of Transmission Timing Belts on DP.1596. EThis product is not suitable for non-backlash timing pulleys.
EWeight is a theoretical value for reference only, which may be different from that of the actual product. Idlers / Timing Belts Timing Pulleys /
1Type 2Belt Type 3Nominal Width 4Number of Teeth Allowable tension (N)
(1 tooth increments)
100 (10mm) 196
150 (15mm) 291
T5 40~10000
200 (20mm) 394
250 (25mm) 497
C-TTBO 150 (15mm) 523
200 (20mm) 695
250 (25mm) 926
T10 40~5000
300 (30mm) 1097
400 (40mm) 1509
500 (50mm) 1862
ETotal length is (number of teeth × pitch). Ekgf=N×0.101972
EThe allowable tension is only the permissible value associated with the tensile load.
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering
Example Part Number 1Type - 2Belt Type · 3Nominal Width - 4Number of Teeth
C-TTBO - T5100 - 200
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By
Type C-TTBO Keyword open belt MISUMI
Economy series
