Page 590 - MISUMI SINGAPORE Economy Series

Timing Belts S8M type

Timing Pulley New Representative model: C-HTBN480S8M-300
Specs
Save Up to
P.529
vs Standard Type 80% Shipping
from
Idlers 6.44 SGD 1 day

Volume Discount
P.551 Quantity 1~29 30~
Timing Belts E Shipping days may differ by Quantity. 30%
Discount
Unit Price
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material
P.577 1Back Rubber 2Tooth Rubber 3Core Wire 4Tooth Fabric
Closed End Belts Chloroprene Rubber Chloroprene Rubber Glass Fiber Nylon Cloth

P.605 3 Pitch: 8mm 1 PLD Back side
Lr
Open End Belts H i h Toothed Face

P.611 Ra 4 2
Clamp Plates for Open End Belts Types Nominal Pitch (mm) Ra Lr H h i PLD Unit weight g/m

Width
(Width: 10mm)
150
P.615 (15mm)
5 S8M (25mm) 8 5.2 5.2 5.3 3.05 2.25 0.686 52
250
300
Timing Pulleys / Idlers / Timing Belts EBelt circumference length is core wire length. EBelt operating temperature range: -30 to 90 °C.
(30mm)
400
(40mm)
EThe model engraved on the back of the product is the factory-managed model, which may be different from the actual product.
EFor the transmission capacity and calculation and design method of economy series timing belt, please refer to the national standard (GB) design manual.
EWeight is a theoretical value for reference only, which may be different from that of the actual product.
Part Number 3Nominal Number Belt Circumference Part Number 3Nominal Number Belt Circumference
1Type 2Belt Number Width of Teeth Length (mm) 1Type 2Belt Number Width of Teeth Length (mm)
376S8M 47 376 672S8M 84 672
400S8M 50 400 680S8M 85 680
408S8M 51 408 704S8M 88 704
424S8M 53 424 712S8M 89 712
432S8M 54 432 720S8M 90 720
440S8M 55 440 728S8M 91 728
464S8M 58 464 736S8M 92 736
150
150
480S8M (15mm) 60 480 744S8M (15mm) 93 744
496S8M 62 496 752S8M 94 752
250
250
512S8M (25mm) 64 512 760S8M (25mm) 95 760
C-HTBN 520S8M 65 520 C-HTBN 768S8M 96 768
300
300
528S8M (30mm) 66 528 776S8M (30mm) 97 776
560S8M 70 560 784S8M 98 784
400
400
584S8M (40mm) 73 584 792S8M (40mm) 99 792
592S8M 74 592 800S8M 100 800
600S8M 75 600 816S8M 102 816
608S8M 76 608 824S8M 103 824
616S8M 77 616 832S8M 104 832
632S8M 79 632 840S8M 105 840
640S8M 80 640 848S8M 106 848
656S8M 82 656 856S8M 107 856
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By MISUMI
585 Type C-HTBN Keyword belt s8m Economy series
