Toggle Clamps Side Push Type, 2270N, Casted steel

Representative model: C-LD-304CM
Save Up to
vs Standard Type 80% Shipping
7.74 SGD 1 day
from

Volume Discount
Quantity 1~29 30~
Discount Unit Price 30%
E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Part Number C-LD-304CM 4- φ 6.7 Through Hole 4-12 Depth 0.5 1N=0.101972kgf
Body Material Cast Steel Female Thread
Handle Material PVC Depth 30.2
Body Surface Treatment Electrophoresis (Black) 41.1 57
Shaft Surface Treatment None
Closing Pressure (N) MAX 2270 M8×1.25 φ 12.6 35
Mass (g) 340 52
Arm Open-Close Angle /
Handle Open-Close Angle 186° Stroke 32
Accessories Steel Hexagon Flat Head Bolt (76)
Bolt M8
10 E Actual product color may be a bit different 4.5 25.4 Ordering Part Number
from photo. (55) (126) (54) Example C-LD-304CM
Plungers / Toggle Clamps Toggle Clamps Side Push Type, 3860N, Casted steel

Representative model: C-LD-304EM

Save Up to
Ball Plungers vs Standard Type 64% Shipping
from
P.817 8.68 SGD 1 day
Spring Plungers Volume Discount Unit Price 30%
1~29
Quantity
30~
Discount
P.826 E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
4- φ 8.3
Index Plungers Part Number C-LD-304EM Female Thread Depth 40 4-13 Depth 0.8 1N=0.101972kgf
Cast Steel
Body Material
Handle Material
PVC
Shaft Surface Treatment
None
P.830 Body Surface Treatment Electrophoresis (Black) 41.1 57.2
Closing Pressure (N) MAX 3860 M10×1.5 φ 15.9 41.1
Mass (g) 580 58.8
Toggle Clamps Arm Open-Close Angle 184° Stroke 42
/
Handle Open-Close Angle
Accessories
M10
Bolt Steel Hexagon Flat Head Bolt (5.4) (91)
P.840 E Actual product color may be a bit different 31.8 Ordering Part Number
from photo. (81) Example C-LD-304EM
(163) (72)
