Page 779 - MISUMI SINGAPORE Economy Series

Part Number Load Capacity Minimum
Stage Surface Travel (N) Straightness Reading Mass (kg)
(mm) Distance (mm) (µm)
1Type 2No. Horizontal (μm)

25 25×25 ±3.25 39.2 0.07

40 40×40 98 0.23
±6.5
E-XSG 60 60×60 196 Within 10 10 0.4
9
80 80×80 264.6 0.9

±12.5
100 100×100 343 1.33 Screws / Positioning Stages Locating Pins / Bushings / Clamping

Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering
Example Part Number (1Type · 2No.) - 3Alterations
E-XSG40
E-XSG40 - A Pins Locating
Alteration
P.745
Alterations 3Alterations to Micrometer Knob Position
Center Center Left-Right Center Top-Bottom Center Left-Right / Side Left-Right Locating Pins
Reversed Reversed Top-Bottom Reversed Reversed Bushings for

P.749
Spec. Bolts Adjusting

P.753
Code A AR AZ AZR CR
Alterations 3Alterations to Micrometer Knob Position Screws Clamp
Side Top-Bottom Left-Right / Disc Clamp Opposed Clamp No Micrometer Head
Reversed Top-Bottom Reversed P.760

Spec. Pushers Urethane

P.763

Code CZ CZR H P MN Heads Micrometer

P.767

Motorized
Positioning Stages
P.769
