Page 783 - MISUMI SINGAPORE Economy Series

Part Number Load Capacity Minimum
Stage Surface Travel (N) Straightness Reading Mass (kg)
1Type 2No. (mm) Distance (mm) Horizontal (µm) (μm)

25 25×25 ±3.25 38.2 0.14

40 40×40 95 0.46
±6.5
E-XYSG 60 60×60 192 Within 10 10 0.8

80 80×80 255 1.8
±12.5 9
100 100×100 329 2.66

Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering Screws / Positioning Stages Locating Pins / Bushings / Clamping
Example Part Number (1Type · 2No.) - 3Alterations
E-XYSG40
E-XYSG40 - A

Alteration
Alterations 3Alterations to Micrometer Knob Position Pins Locating
Center Center Left-Right Side Left-Right Side Top-Bottom Left-Right /
Reversed Reversed Reversed Top-Bottom Reversed
P.745

Spec. Locating Pins Bushings for
P.749

Bolts
Adjusting
P.753
Code A AR CR CZ CZR

Alterations 3Alterations to Micrometer Knob Position Screws Clamp
Disc Clamp Opposed Clamp No Micrometer Head
P.760

Spec. Pushers Urethane
P.763

Heads
Code H P MN P.767
Micrometer

Motorized
Positioning Stages
P.769
