Page 785 - MISUMI SINGAPORE Economy Series

Part Number Load Capacity Minimum
Stage Surface Travel (N) Straightness Reading Mass (kg)
1Type 2No. (mm) Distance (mm) Horizontal (µm) (μm)

40 40×40 88 0.34

±6.5

60 60×60 186 0.64

E-XYSSG Within 10 10 9

80 80×80 196 1.32 Screws / Positioning Stages Locating Pins / Bushings / Clamping

±12.5

100 100×100 245 2 Pins Locating

Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering P.745
Example Part Number (1Type · 2No.) - 3Alterations
E-XYSSG40
E-XYSSG40 - A Locating Pins Bushings for

Alteration
P.749
Alterations 3Alterations to Micrometer Knob Position
Center Side Left-Right Reversed No Micrometer Rotation Bolts Adjusting

P.753

Spec. Screws Clamp
P.760

Pushers
Urethane
P.763
Code A CR MN Heads Micrometer

P.767

Motorized
Positioning Stages
P.769
