Economy series Product Overview
Micrometer Heads

vs Standard Type
Economy series Saving
up to
Micrometer Heads 77 %

2 shapes, 8 models

Easy to use
9 Strong locking force Without nut type
Locating Pins / Bushings / Clamping Screws / Positioning Stages Space saving With nut type

QFeatures of MISUMI Economy Series
Locating Pins

P.745
Bushings for Locating Pins

P.749
Adjusting Bolts Hexagon Nut Set Screw Scale Line

· Convenient because an ordinary
hex wrench can be used and no · Locking with a hexagonal The position of the main
wrench, large torque, no shift
scale line and the locking
P.753 special tool is required.
· Not easy to interfere in a small space · Embedding, space saving device are on the same line,
which is easy to operate in a
Clamp Screws small space
P.760
Urethane Pushers QExample of Use

P.763 Adjusting Screw
Micrometer Heads

P.767 Micrometer Precise movement of the table position can be achieved by the
Heads cooperation of the micrometer head and the adjusting screw.
Motorized Positioning Stages · Loosen the adjusting screw;
· After rotating the micrometer head to the desired position,
lock the set screw with a hexagonal wrench;
P.769 · Tighten the adjusting screw until the table is completely locked.
