Page 537 - MISUMI SINGAPORE Economy Series

Part Number 5Shaft Bore Specs. N Pulley Timing
1Type 2Number of Teeth 3Belt Type 4Pulley Shape Hole Dia. d P.D. O.D. F E
S2M040 8
32 S2M060 8 20.37 19.86 25 16 P.529
S2M100 8
S2M040 10
34 21.65 21.14 25 16
S2M100 8
S2M060 8 Idlers
36 22.92 22.41 28 18
C-HTPA 40 S2M100 A 10 25.46 24.96 30 20
10
44 S2M060 8 28.01 27.5 32 23 P.551
15
48 30.56 30.05 35 25
S2M100 14
50 15 31.83 31.32 35 25
S2M060 Timing Belts
60 12 38.2 37.69 44 32
S2M100 19
Part Number 5Shaft Bore Specs. P P.577
1Type 2Number of Teeth 3Belt Type 4Pulley Shape Hole Dia. d P.D. O.D. D F E
S2M040 6
32 20.37 19.86 12 25 16
S2M060 5
C-HTPA 36 S2M100 B 8 22.92 22.41 14 28 18 Belts Closed End
40 8 25.46 24.96 18 30 20
44 S2M040 5 28.01 27.5 20 32 23
48 S2M060 6·6.35 30.56 30.05 20 35 25 P.605
Part Number 5Shaft Bore Specs. N
1Type 2Number of Teeth 3Belt Type 4Pulley Shape Hole Dia. d P.D. O.D. D F E
S2M060 8 Belts Open End
40 25.46 24.96 18 30 20
C-HTPA S2M100 B 8
50 S2M060 10 31.83 31.32 20 35 25
60 S2M100 8 38.2 37.69 30 44 32 P.611
Part Number 5Shaft Bore Specs. P
1Type 2Number of Teeth 3Belt Type 4Pulley Shape Hole Dia. d P.D. O.D. D F E
S2M040 4 Open End Belts Clamp Plates for
14 8.91 8.4 12 12 6
S2M060 3·4
S2M040 5
16 S2M060 4·5 10.19 9.68 14 14 8 P.615
S2M100 5 5
C-HTPA S2M040 K 4·5
18 S2M060 4·5 11.46 10.95 14 14 8
S2M100 5
S2M040 3·4·5·6
20 S2M060 5·6 12.73 12.22 16 16 10
S2M100 5·6 Idlers / Timing Belts
22 S2M060 5 14.01 13.5 18 18 11 Timing Pulleys /
Part Number 4Pulley Shape 5Shaft Bore Specs. H P.D. O.D. D F E
1Type 2Number of Teeth 3Belt Type Hole Dia. d
14 S2M040 3 8.91 8.4 12 12 6
C-HTPA K
20 S2M040 5 12.73 12.22 16 16 10
Please order after selecting part number and parameters according to the selection steps 1 to 5.
Ordering
Example Part Number (1Type · 2Number of Teeth · 3Belt Type) - 4Pulley Shape - 5Shaft Bore Specs. / Hole Dia. (H/P/N)
C-HTPA26S2M060 - K - P8
