Page 907 - MISUMI SINGAPORE Economy Series

Economy series Product Overview Product Overview Economy series
Photo Microsensors Photo Microsensors

· Advantage 3 Widened welding spot spacing of substrate, fully automatic welding process, and not easy to
Economy series short circuit * MISUMI Economy series

Generic products on the market
Photo Microsensors

Welding spot Sensor Proximity
High accuracy detection spacing of

Free switching between Normally The welding substrate is P.891
widened to
Open (NO) and Normally Closed (NC) spot spacing 2.6mm Fixed
of substrate is Microsensors Photo
Complete specifications, with NPN, only 2.1mm cable
PNP Cable type, Connector type position, and
not easy to P.901
short circuit Sensors Zone

Q Advantages of MISUMI Economy series groove type sensors · Advantage 4 : Full automatic inspection, with guaranteed product quality P.913

· Advantage 1 : Power supply reverse connection , output reverse connection , output short circuit 3 circuit
protection circuits as standard Q Full automatic inspection equipment Q13 tests completed at one time Filters

Generic products on the market * MISUMI Economy series Initialization Settings Consumption Current Test (Normally Closed) P.918
(Normally Closed) Load Current and Residual Voltage Test
Q Output Circuit Diagram DC 4-Wire Type NPN Output
Light ON Indicator (Red) + * Cable Color Pause Message Consumption Current Test (Normally Open) Strips Power
L (Brown) +V (Normally Open) Load Current and Residual Voltage Test
Load
Load Short Circuit Protection Test (Normally Closed) Short Circuit Protection Test (Normally Open) P.921
OUT DC (Black) Output 1 (Note 1) Load 5~24V DC
Main IC (Control Output) 5~24V Main Circuit Tr1 ±10% Power Supply Reverse Connection Protection Test Tail Swing Test
Circuit 100mA or Less ZD2 (White) Output 2 (Note 1) Oscilloscope Frequency Test (Normally Open) Oscilloscope Frequency Test (Normally Closed) Probes Contact
- Tr2 ZD1 (Blue) 0V
Test End
Internal Circuit External Connection Example P.924
* Generic products on the market are similar products randomly purchased by our company from online or offline markets 12
Output short circuit
No protection circuit
Power supply reverse connection Protection circuit Output reverse connection QUsage Method Power Strips / Contact Probes Sensors / Filters /

· Advantage 2 Improved tail plug, not easy to come out, vibration resistant structure
QMounting Method M3 Screw QConnector Type
Generic products on the market * MISUMI Economy series · When fixing the body with Spring Washer · Plugging and unplugging steps of connector Hook
screws, use M3 screws,
φ6mm washers and Flat Washer 1 Insert the connector directly into Wiring Tab
control the tightening (O.D. φ6mm) the sensor until the connector tab is
torque below 0.5N·m locked in place by the sensor hook.
QWelding (Sensor)
· If welding directly on the terminal, please strictly follow the 5N or Less
conditions given below. 2 When pulling out, make sure that
Welding Sensor 1.5mm enough force is applied to release
Temperature 260℃ or Less the connector tab from the hook.
Welding 3S or Less Then pull it off.
Time Welding
Welding Refer to the Position Precautions: Make sure to hold the connector when
Position right diagram
plugging and unplugging it. In addition,
do not hold terminals or cables.
No protection measures, easy to loosen With tail plug snap inside, the wire is not easy to loosen Otherwise, it will cause poor contact.
