Page 847 - MISUMI SINGAPORE Economy Series

Toggle Clamps Horizontal, Hold Down Pressure 900N, High Position

Representative model: C-LD-201BHB
Save Up to
vs Standard Type 74% Shipping
4.56 SGD 1 day
from

Volume Discount
Quantity 1~49 50~99 100~
Discount Unit Price 15% 30%
E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Part Number C-LD-201BHB (35) 1N=0.101972kgf
Body Material A3
Handle Material PVC 36 22 7
Surface Treatment Blue Zinc Electroplating 4-Slotted Hole 5.5×6.3 0.8 25.4
Closing Pressure (N) MAX 900 27
Mass (g) 146 37
Arm Open-Close Angle 80° M6×1
Handle Open-Close Angle 73°
Accessories Rubber Head Bolt 12.7 (112)
Bolt M6 51
E Actual product color may be a bit different 43
from photo. 2 Ordering Part Number 10
57 Example
(143) C-LD-201BHB
Toggle Clamps Horizontal, Hold Down Pressure 264N Toggle Clamps Plungers /

Representative model: C-LD-201A

Save Up to
vs Standard Type 80% Shipping Plungers Ball
1.92 SGD 1 day P.817
from

Volume Discount
Quantity 1~49 50~99 100~ Plungers Spring
Discount Unit Price 15% 30%
E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part. P.826
Part Number C-LD-201A 4-Slotted Hole 4.4×6.8 1N=0.101972kgf
Body Material A3 φ 9.4 Plungers Index
Handle Material PVC
Surface Treatment Blue Zinc Electroplating 23.8 15.9 9.4
Closing Pressure (N) MAX 264 P.830
Mass (g) 30 2.4 11.1
Arm Open-Close Angle 90° 15.9
23.8
Handle Open-Close Angle 73°
Accessories Hexagon Nylon Bolt Clamps Toggle
Bolt M4 M4×0.7
E Actual product color may be a bit different (48)
from photo. 3 Ordering Part Number P.840
1.5 22.5 9.8 17.4 Example C-LD-201A
18.5
23 (71)
