Leveling Mounts Metal Body, Universal Type

New Representative model: E-CFJFND80-16-100
Products
Save Up to
vs Standard Type 41% Shipping
16.80 SGD 5 days
from

Volume Discount
Quantity 4~9 10~
Discount Unit Price 30%
E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material Surface Treatment
Type
Thread Base Thread Base
E-CFJFND Steel (Q235) Zinc Plating
E-CFJFNDS SUS304 Polishing

3M (Coarse Thread)
L1 L2

2D
Casters 15°

P.1289 H
Caster With Leveling Mounts E 4A B

L
P.1344 E The bottom of the product is hollow.
Body
Part Number 3Thread 4Thread Height R1 R2 E H B Allowable
Leveling Mounts 1Type 2Width D size M Length A 135.5 Load (kN)
L
100
16
150 185.5 10 13 24 10
P.1346 80 100 138.5 21.5 10
18 E-CFJFND 20 150 188.5 13 16 30 15
180
218.5
Casters / Leveling Mounts E-CFJFNDS 100 20 100 141.5 13 16 24.5 13 30 20
(Q235)
150
191.5
(SUS304)
180
221.5
100
142.5
24
150
222.5
180 192.5 14 19 36 25
E “Allowable load” in this specification table is for the vertical direction only
E For more information on product specifications and dimensional drawings, please refer to product catalog on the website.
Please order after selecting part number and parameters according to the selection steps 1 to 4.
Ordering
Example Part Number (1Type · 2Width D) - 3Thread size M - 4Thread Length A
E-CFJFND80 - 16 - 100
