Page 1357 - MISUMI SINGAPORE Economy Series

Leveling Mounts Metal Pad Standard

Representative model: C-CNFJN10-100
Save Up to
vs Standard Type 59% Shipping
1.34 SGD 1 day
from

Volume Discount
Quantity 1~49 50~99 100~
Discount Unit Price 15% 30%
E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material Surface Treatment
Type
Thread Base Thread Base
C-CNFJN Steel (Q235) Steel (Q235) Zinc Plating Zinc Plating
C-CNFJNS SUS304 SUS304 Natural Color Electrolytic polishing

D
2M (Coarse Thread)

t R2
E R1 3A
L B Casters
E The bottom of the product is hollow. P.1289
Part Number 3Thread Body Height Width E B t Allowable Load
1Type 2Thread size M Length A L D R 1 R 2 (kN)
80 99.5 Leveling Mounts Caster With
10 38 7 8 12.5 17 1.6 4
119.5 P.1344
100
128
12 60 8 10 20 19 4.5 Mounts Leveling
120 148
C-CNFJN
(Q235) 100 132 P.1346
18
C-CNFJNS 16 120 152 10 13 24 5.5
(SUS304) 2
150 182
75 22
120 155 Mounts Casters / Leveling
20 150 185 13 16 30 6.8
200 235
E “Allowable load” in this specification table is for the vertical direction only
E For more information on product specifications and dimensional drawings, please refer to product catalog on the website.
Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering
Example Part Number (1Type · 2Thread Size M) - 3Thread Length A
C-CNFJN10 - 100
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By MISUMI
Type C-CNFJN Keyword leveling mount
Economy series
