Economy series Product Overview Product Overview Economy series 19
Hinge Hinge

vs Standard Type Q Aluminum Alloy Heavy Load Hinge LED Lighting / Signal Towers Handles / Hinges / Knobs / Slide Rails /
Economy series Saving · The material of the mechanism of the central shaft is changed to realize the allowable load force UP
up to
Reducing design change costs and improving design versatility
Hinge 77 % Aluminum alloy heavy load type compared with MISUMI standard products by same size and specification, Handles
the load can be increased by 2 times.
Reducing design modifications due to load limitations, parts management costs, and assembly difficulties
Wide Range of Products, P.1367
applicable to a variety of Allowable Load (N) Aluminum Alloy Heavy Load Type
installation requirements, 200 196 Hinges
Effectively reduce costs P.1383

Load is increased
150 by 2 times Catches Magnetic

Heavy Load Heavy Load
98 P.1405
100 Tapered Hole Type Asymmetric Type
Q Advantages of MISUMI Economy series Test Conditions:
· Fine workmanship, and quality assurance · Improved structure, firm and durable The center axis of the hinge is parallel to the Locks
50 extension line of the center of gravity of the door.
Aluminum Hinge Stainless Steel Hinge P.1414
Using the test door body: Length = 2 × Width
Generic products on the market * MISUMI Economy series Generic products on the market * MISUMI Economy series 0 After installation, there is no visible change in
Mounting holes are inaccurate Full inspection of all products with Ordinary riveted central shaft, small contact Modification of the central shaft structure, contact surface MISUMI Economy series MISUMI opening and closing, which is regarded as the Knobs
and cannot be assembled special fixtures, ensuring quality area, easy to fall off, and not firm enhancement, additional welding joints, firm and durable Heavy Load Type standard product effective allowable load.
P.1431
* The allowable load is the value when 2 pieces are used
QStainless Steel Heavy Load Hinges with Bearings Rails Linear Slide

· Additional auxiliary bearings to reduce the opening and closing resistance, ensuring safe and efficient use
Relieving the friction of hinge opening and closing, and reducing the opening and closing starting force P.1448
For stainless steel heavy load hinges with bearings, compared with MISUMI standard product, the opening
and closing starting force is reduced by 56%. LED Lighting
Reducing friction of parts, and alleviating opening and closing noise
* Generic products on the market are similar products randomly purchased by our company from online or offline markets Heavy Load Type With Bearings P.1466
Rotating Starting Force (N)
QExample of Use
80 Signal Towers
Aluminum Hinge Stainless Steel Hinge
64
Suitable for aluminum alloy frames, and adapted to Highly versatile and suitable for a variety of door frame materials, especially P.1475
the opening of profile groove size for equipment with high overall weight of the door or requiring high load. 60 Rotating Starting Force
Reduced by 56%

40
28

20

0
MISUMI MISUMI Economy series
standard product Heavy Load Type with Bearings

* The test data are obtained through testing by our company, which are for reference only.
