Three Phase Noise Filters

New Representative model: E-SNF-10
Products

Shipping
55.70 SGD 5 days
from

Volume Discount
Quantity 1~9 10~ Sensor Proximity
Discount Unit Price 30%
E Shipping days may differ by Quantity. P.891
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Screw Mounting DIN Rail Mounting
120 120 Microsensors Photo
2× φ 4.5 110 2× φ 4.5 110
Mounting Hole Mounting Hole
Output Terminal Output Terminal P.901
Input Terminal Output Terminal Input Terminal
53 63 53 63 Output Terminal
Input Terminal Output Terminal Input Terminal Output Terminal Sensors
Input Terminal Input Terminal Zone
7-M4 Mounting Plate 7-M4
Terminal Ground Protection Terminal Ground Protection
Cover Cover P.913

42 Filters
42

8.4 P.918
Screw Mounting E-SNF-10 E-SNF-20 E-SNF-30 Strips Power
DIN Rail Mounting E-SNF-10D E-SNF-20D E-SNF-30D
Rated Current (AC / DC) 10A 20A 30A
P.921
Rated Voltage (AC / DC) 500V 500V 500V
Withstand Voltage AC 2500V 60s Terminal - Grounding
Insulation Resistance 100MΩ min. at DC 500V Probes Contact
Leakage Current 2.5mA max. at AC 250V / 60Hz 5.0mA max.@ AC 500V / 60Hz
Direct Current Resistance 60mΩ max. 25mΩ max. 13mΩ max. P.924
Operating Environment Temperature -25~85°C, Humidity 20~95%RH (no condensation) 12
Common Mode
Differential Mode
E-SNF-10 E-SNF-20 E-SNF-30
0
0 E-SNF-10D -10 0 E-SNF-20D -10 E-SNF-30D Power Strips / Contact Probes Sensors / Filters /
-10
Attenuation(dB) -30 Attenuation(dB) -30 Attenuation(dB) -30
-20
-20
-20
-40
-40
-40
-50
-50
-50
-60
-60
-60
-70
-80
-80 -70 -70
-80
-90 -90 -90
-100 -100 -100
0.1 1 10 100 0.1 1 10 100 0.1 1 10 100
Frequency(MHz) Frequency(MHz) Frequency(MHz)
Ordering
Example Part Number (Type)
E-SNF-10
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By MISUMI
Type E-SNF-10 Keyword noise filter Economy series
