Page 821 - MISUMI SINGAPORE Economy Series

Sheet Metal Bending Fixture Reference price

Application Industries: Automotive Part Electronic & Electrical

This figure shows a simple sheet metal bending fixture composed of toggle clamps and
index plungers, with simple structure and easy operation.
By selecting different toggle clamps, combined with index plungers and other positioning 49.26 SGD/set
and clamping products, functional tooling positioning fixtures can be built for different
purposes.

01 Index Plunger × 1 02 Ball Plunger × 2

01 Index Plunger × 1 P.834 02 Ball Plunger × 2 P.824

Locking Mechanism Reset Type O.D. M3
Surface Treatment Blackening Stroke 0.6mm
Thread O.D. M10 C-PFPPN3-20P
C-PMXSB10

3.02 9.68

SGD/pcs SGD/pack
Quantity Unit price Total price Quantity Unit price Total price
1 3.02 3.02 1 9.68 9.68
50 2.57 128.50 30 6.78 203.40

03 Linear Guide × 2 P.311 04 Toggle Clamp × 2 P.852

Nominal Model 7 Side Push Type 450N
Length 55mm C-LD-301AM
E-GMLG7-55

14.98 3.30
04 Toggle Clamp × 2 03 Linear Guide × 2
SGD/pcs SGD/pcs
Quantity Unit price Total price Quantity Unit price Total price
1 14.98 14.98 1 3.30 3.30
10 11.99 119.90 50 2.81 140.50
* All products prices are without tax. For prices reference, please visit MISUMI official website.
* The reference price is estimated based on the quantity or approximate length of the product used in the example and is not 816
calculated using the price for the minimum order quantity.
