Page 795 - MISUMI SINGAPORE Economy Series

Part Number Minimum
Stage Surface Travel Load Capacity Straightness Reading Mass (kg)
1Type 2No. (mm) Distance (mm) (N) (µm) (μm)

40 40×40 9.8 0.48

±6.5
9

E-XYZPG 60 60×60 19.6 Within 20 10 0.95 Screws / Positioning Stages Locating Pins / Bushings / Clamping

80 80×80 ±12.5 49 1.8 Pins Locating

P.745

Please order after selecting part number and parameters according to the selection steps 1 to 3.
Ordering Locating Pins Bushings for
Example Part Number (1Type · 2No.) - 3Alterations
E-XYZPG60
E-XYZPG60 - A P.749
Alteration

Alterations 3Alterations to Micrometer Knob Position Bolts Adjusting
Center Side Up Side Down Reversed P.753

Screws
Clamp
P.760
Spec. Pushers Urethane

P.763

Heads
Code A C CU R P.767
Micrometer

Motorized
Positioning Stages
P.769
