Economy Series
Product Overview Flat Washers / Metal Collars

vs Standard Type
Saving
Economy Series up to
Flat Washers & 80 %

Metal Collars

CNC Machining
21
Accuracy Assurance

Popular specifications
Widely Used Magnets / Keys / Shims Screws / Collars /

Q Specification difference between Economy series and MISUMI standard product

· Flat Washers Screws
Suitable for fixed parts or spacing, etc. with general strength requirements
Difference Points MISUMI standard product MISUMI Economy Series P.1495
Material Equivalent to S45C Low Carbon Free Cutting Steel

Surface Treatment Ferroferric Oxide Protective Film or Electroless Nickel Plating Trivalent Chromate Treatment Washers
D*=16 or Less C0.2 or Less
Chamfer D=20 or More C0.5 or Less Micro chamfer P.1498
· Metal collar
Suitable for fixed parts or adjusting height Metal Collars
Difference Points MISUMI standard product MISUMI Economy Series
P.1501
Material Equivalent to S45C General structural steel or carbon steel
Surface Treatment Ferroferric Oxide Protective Film or Electroless Nickel Plating Trivalent Chromate Treatment Shim Tapes
Chamfer D*=16 or Less C0.1~C0.2 Micro chamfer
D=20 or More C0.5 or Less
* D means outside diameter P.1502
Q Example of the main use of washer 1
· For spring washers Flat Washers · For fixing bearings Flat Washers Parallel Keys

P.1504

Flat Washers Magnets

Q Example of the main use of collar 2 P.1507
· For spacing adjustment Metal Collars · For height adjustment
or cushioning
Metal
Collars
