Motor-Driven Ball Screw Linear Drive Mechanism

Application Industries:
Automotive part Packaging Medical

This figure is a case of a linear drive
mechanism driven by a stepper motor, which is Reference price
widely used in industrial automation production
fields such as automotive parts manufacturing,
packaging, and medical care. 210.29 SGD/set

01 Motor ×1 P.497 02 Rolled Ball Screw ×1 P.47

Type Motor + Driver 42 Series Shaft Dia. 10
Body Length 31mm Lead 4mm
Number of Leads 4 Threaded Shaft 450mm
Holding Torque 0.22N·m C-TBSE1004-450
C-42STM01+DR42A
50.89 156.90
SGD/set SGD/pcs
Quantity Unit price Total price Quantity Unit price Total price
1 50.89 50.89 1 156.90 156.90
10 35.63 356.30 10 125.52 1,255.20

03 Coupling ×1 P.520

Slit Shaped
O.D. (φ) 20mm
Shaft Hole Dia. 1 (φ) 6mm
Shaft Hole Dia. 2 (φ) 8mm
E-LMPL20-6-8
2.50

SGD/pcs
Quantity Unit price Total price
1 2.50 2.50
50 2.00 100.00
