Page 1070 - MISUMI SINGAPORE Economy Series

Suction Cups MZ Series Nozzle Type, With Pad / Unit

New Representative model: E-MZ2AN0.8-N-M5
Products

Shipping
7.00 SGD 5 days
from

Volume Discount
Quantity 1~29 30~
Discount Unit Price 30%
E Shipping days may differ by Quantity.
E Quantity of volume discount above is for representative Part No. It may differ by the Part.
Material
Surface Treatment
15 Metal Part Material / Brass Hardness Color Suction Cup Units Suction Cup with Connector (Male Thread)
Electroless Nickel Plating
M5×0.8
Suction Cup Material
Suction Cups / Vacuum Generators / Filters Conductive Silicon Rubber Shore A60 Milky White φ4 Width Across Flats 7
Nitrile Rubber
Black
Silicon Rubber
Black
3.5
Suction Cups 8 14.5

P.1031
φA φA
Vacuum Generators Part Number

P.1071 1Type 2Cup Dia. 3Suction Cup Material 4Connector A

Filters 0.8 (Nitrile Rubber) - 1.6
N
E-MZ2AN S (Suction Cup Units)
(Silicon Rubber)
M5
P.1071 (Conductive Silicon Rubber) (Male Thread)
GS
Pressure Sensors 1.1 2

P.1081 Ordering Please order after selecting part number and parameters according to the selection steps 1 to 4. Q Suction Cup Material Specifications
Example Part Number (1Type · 2Cup Dia.) - 3Suction Cup Material - 4Connector Conductive Silicon
E-MZ2AN0.8 - N - M5 Suction Cup Material Nitrile Rubber Silicon Rubber Rubber
Limit Temperature 110°C 180°C 180°C
for High Temperature Use
Limit Temperature -30°C -50°C -40°C
for Low Temperature Use
Weather Resistance △ G P
Ozone Resistance △ P P
Acid Resistance △ G G
Alkali Resistance G P P
Oil Resistance (Gasoline / Light Oil) P △ △
(Benzene / Toluene) △ △ △
Surface Resistivity - - 10 ~10 Ω/sq
6
9
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By
Type E-MZ2AN Keyword suction mz MISUMI
Economy series
