Page 758 - MISUMI SINGAPORE Economy Series

Economy series Product Overview
Adjusting Bolts

vs Standard Type
Economy series Saving
up to
Adjusting Bolts 54 %

Smooth assembly
High precision thread
9 Excellent anti-rust performance
Locating Pins / Bushings / Clamping Screws / Positioning Stages

QAdjusting Bolt Overview
Locating Pins · The adjusting bolt is often used together with

the fixing block for the adjusting bolt.
P.745 · Thread connecting positioning stage for front
Bushings for Locating Pins · The adjustment method is generally divided
and rear position adjustment

P.749 into two types:
1 Manual adjustment with knurling at low load
Adjusting Bolts 2 Adjustment with hex wrench at high load * This design allows to use the
adjusting bolt to simply adjust the
mechanism in XYZ direction.
P.753
QCustomer Voice
Clamp Screws 1 For outgoing processed products, it often happens that the adjusting block cannot be installed because
the groove outer diameter or groove width is poor.
2 The thread accuracy is not good, sometimes not smooth enough in the adjustment and sometimes too loose.
P.760 3 Most surface treatment of outgoing processed products is blackened with poor rust prevention performance.
Urethane Pushers 1 Guaranteed groove tolerance for smooth assembly 2 High precision thread MISUMI Economy series
+0.2
Generic products on the market
Guaranteed accuracy
T
+0.1
and groove outer diameter
· During assembly, the thread is often
· Ensure smooth
P.763 tolerance of groove width · No inspection standard · Full inspection before shipment
adjustment during use
too tight and cannot be screwed
Micrometer Heads -0.1 d -0.2 * Problems of generic products on the market.
P.767 3 Excellent anti-rust performance
Motorized Positioning Stages Blackened product severely rusted Trivalent chromate treatment with
24h Salt Spray Test Results
P.769 Full assembly slight white rust and no rusting
confirmation before shipment
Ensure smooth assembly
with the adjusting block
* Generic products on the market are similar products randomly purchased
by our company from online or offline markets
* The test data are obtained through testing by our company, which are for reference only.
753
