Page 1333 - MISUMI SINGAPORE Economy Series

Light Load Urethane Casters Swivel Type, Wheel width 32mm

Material Surface Treatment
Body Steel Zinc Plating
Wheel Urethane (Dark Red) -
Plate Mount X
r

H 8.5 45 64
D 3.5
Not 74 Casters

32 E 95
Screw-in Mount X X M12 X View P.1289
Available Leveling Mounts Caster With
M12
37
37
r r
P.1344
15.8 15.8
H H
D D Mounts Leveling
X View
32 E E
32
P.1346
18
Allowable
Part Number Mount Type D H E r Load Mass
(g)
(daN)
E-DL13-20PU-100 Plate Mount 100 130 31.5 108 110 770 Mounts Casters / Leveling

E-DL15-20PU-100CV Screw-in Mount 100 130 31.5 108 110 770
E Product images are for representative purposes only.
Ordering
Example Part Number
E-DL13-20PU-100
How to search Search on MISUMI official website Step 1 Input Search Keyword Step 2 Select Brand Brand
on website By By
Type E-DL Keyword urethane caster swivel MISUMI
Economy series
